| Related Load (kg.) 100, 200, 300, 500 | |
| Precision C3 | Insulation Resistance(MΩ@VDC) ≥5000(50) |
| Composition Error0.02 | Excitation Voltage (VDC)9~12 |
| Rated Output (mv/v)2 ± 5 | Compensated temp. Range (°C)-10~+40 |
| Non-Linearity (%FS)0.017 | Use Temp. Range (°C)-35~+65 |
| Hysteresis (%FS)0.02 | Temp. Effect on Zero (%FS/10°C)0.017 |
| Repeatability (%FS)0.01 | Temp. Effect on Span (%FS/10°C)0.017 |
| Creep (%FS/30min)0.02 | Safe Overload (%FS)120 |
| Zero Balance (%FS)± 1 | Ultimate Overload (%FS)150 |
| Input Resistance (Ω)400 ± 10 | Defend GradeIP65 |
| Output Resistance (Ω)350 ± 2 | Cable4mm, 3mtr |
