| Related Load (kg.) 11.25, 22.5 , 45 | |
| Precision C3 | Insulation Resistance(MΩ@VDC) 5000(50) |
| Composition Error 0.02 | Excitation Voltage (VDC)9~12 |
| Rated Output (mv/v) 2.00±2% | Compensated temp. Range (°C)-10~+40 |
| Non-Linearity (%FS)0.017 | Use Temp. Range (°C) -35~+65 °C |
| Hysteresis (%FS)0.02 | Temp. Effect on Zero (%FS/10°C)0.0017 |
| Repeatability (%FS)0.01 | Temp. Effect on Span (%FS/10°C)0.014 |
| Creep (%FS/30min)0.02 | Safe Overload (%FS)120 |
| Zero Balance (%FS)±2 | Ultimate Overload (%FS)150 |
| Input Resistance (Ω)395±5 | Defend GradeIP67 |
| Output Resistance (Ω) 350± 2 | Cable6mm,5.0Mtr |
