CONSTRUCTION MACHINERY LOAD CELL(ABL 60048)

Features:

• Constructed of tool steel for harsh application.
• Moment-compensated design for minimal sensitivity to moments induced by off-center loading.
• Provides optimum protection under adverse loading condition.

Applications:

• Belt conveyor scales
• Bench and counting scale
• Check weighing scales
• Hooper scales & net weighing
• Batching plant
• Construction Machinery

Dimensions:

Related Load (kg.) 22.5,45,90
Precision C3	Insulation Resistance(MΩ@VDC) 5000(50)
Composition Error 0.02	Excitation Voltage (VDC)9~12
Rated Output (mv/v) 2.00±2%	Compensated temp. Range (°C)-10~+40
Non-Linearity (%FS)0.017	Use Temp. Range (°C) -35~+65 °C
Hysteresis (%FS)0.02	Temp. Effect on Zero (%FS/10°C)0.0017
Repeatability (%FS)0.01	Temp. Effect on Span (%FS/10°C)0.014
Creep (%FS/30min) 0.02	Safe Overload (%FS)120
Zero Balance (%FS)±2	Ultimate Overload (%FS)150
Input Resistance (Ω)395±5	Defend GradeIP67
Output Resistance (Ω) 350± 5	Cable6mm, 5.0Mtr
