| Related Load (kg.) 100, 200, 300, 500, 750, 1000, 1500 | |
| Precision C2 / C3 | Insulation Resistance(MΩ@VDC) ≥2000(100VDC) |
| Composition Error 0.03 / 0.02 | Excitation Voltage (VDC) 5~15 |
| Rated Output (mv/v) 2.0 ± 10% | Compensated temp. Range (°C) -10~+40 |
| Non-Linearity (%FS) 0.025 | Use Temp. Range (°C) -20~+60 |
| Hysteresis (%FS)0.02 | Temp. Effect on Zero (%FS/10°C) 0.02 |
| Repeatability (%FS) 0.02 / 0.01 | Temp. Effect on Span (%FS/10°C) 0.015 |
| Creep (%FS/30min) 0.03 | Safe Overload (%FS) 150 |
| Zero Balance (%FS) ± 1.0 | Ultimate Overload (%FS) 250 |
| Input Resistance (Ω) 400 ± 10 | Defend Grade IP65 |
| Output Resistance (Ω) 350 ± 2 | Cable 6mm, 3mtr |
